Minolta 35 Model E
The Minolta 35 Model E is a LTM-mount film rangefinder camera, introduced in 1951. Leica camera price index →
Reference maintained by Thomas Boots
General
- Mount
- LTM
- Release Year
- 1951
- Type
- Film
- Model Number
- Model E
- Serial Range
- Approximately 1518x to 1752x, observed collector range
Dimensions
- Width
- 135mm
- Height
- 75mm
Viewfinder & Shutter
- Magnification
- 0.7x
- Framelines
- None, combined fixed 45 mm viewfinder and coupled rangefinder
- Shutter Speeds
- T, 1 s, 1/2 s, 1/4 s, 1/8 s, B, 1/25 s, 1/35 s, 1/50 s, 1/100 s, 1/200 s and 1/500 s
- Shutter Type
- Cloth
Features
- Hot Shoe
- No
- Tripod Socket
- Yes
- Self Timer
- Yes
- Flash Sync
- Unknown, flashbulb synchronization through a non-PC socket
Minolta 35 Model E
The Minolta 35 Model E is the first member of the series to carry an official model designation on the camera. It combines an LTM mount, hinged back, self timer, 0.7x combined rangefinder/viewfinder and cloth shutter reaching 1/500 second [1].
Model E adds eyepiece dioptre adjustment and replaces the earlier proprietary shoe contact with a rear synchronization socket. Period instructions discuss flashbulbs but do not establish an electronic X-sync speed [1].
History
Development and Launch
The model is generally dated to late 1951, with period advertising continuing into 1952. It followed the collector-classified Model D [1].
Production Evolution
Observed serials run approximately from 1518x to 1752x. Contemporary literature conflicts between nominal 24 x 34 mm and 24 x 34.5 mm frame dimensions, so 24 x 34 mm is the conservative database value [1].
Special Variants
Minor frame-gate and production differences are not separate editions. Model E remains a Standard model.
Collector Notes
Look for the engraved model name at the upper-right front, rotating eyepiece dioptre adjustment and rear non-PC sync socket. Do not confuse it with the very similar Model F, which uses a different connector and revised self-timer markings.
